Partner

You can specify one or more partners of a node by setting their tag to "partner", "left-partner", or "right-partner".

Partner example

{ id: 2, pid: 1, tags: ["partner"] }

Edit in BALKAN Code

Left partner

{ id: 2, pid: 1, tags: ["left-partner"] }

Edit in BALKAN Code

Multiple partners

You can also specify multiple partners.

{ id: 4, pid: 1, tags: ["partner"] },
{ id: 5, pid: 1, tags: ["partner"] },
{ id: 6, pid: 1, tags: ["partner"] },
{ id: 7, pid: 1, tags: ["partner"] }

Edit in BALKAN Code

Children of partners

Children can have parent id pid and parent partner id ppid.

{ id: 1 },
{ id: 2, pid: 1, tags: ["partner"] },
{ id: 3, pid: 1, tags: ["partner"] },
{ id: 4, pid: 1, ppid: 2 },
{ id: 5, pid: 1, ppid: 3 }

Edit in BALKAN Code

Here is an example with a partner's children:

Edit in BALKAN Code

Add a link icon for partners

Use the render-link event in partners to add a link icon.

First define the icon:

OrgChart.templates.ana.defs =
    `<g transform="matrix(0.05,0,0,0.05,-12,-9)" id="heart">
        <path fill="#F57C00" d="M438.482,58.61c-24.7-26.549-59.311-41.655-95.573-41.711c-36.291,0.042-70.938,15.14-95.676,41.694l-8.431,8.909
        l-8.431-8.909C181.284,5.762,98.663,2.728,45.832,51.815c-2.341,2.176-4.602,4.436-6.778,6.778
        c-52.072,56.166-52.072,142.968,0,199.134l187.358,197.581c6.482,6.843,17.284,7.136,24.127,0.654
        c0.224-0.212,0.442-0.43,0.654-0.654l187.29-197.581C490.551,201.567,490.551,114.77,438.482,58.61z"/>
    <g>`;

Then add the event listener before the chart.load() method:

chart.on('render-link', function(sender, args){
    if (args.cnode.ppid != undefined){
        args.html += '<use xlink:href="#heart" x="' + args.p.xa + '" y="' + args.p.ya + '" />'
    }
});

Edit in BALKAN Code

Complex scenario

Edit in BALKAN Code

Partner nodes are very useful for family trees. See the Royal Family Tree demo.
